Warehouse Design

Diversified Rack and Shelving specializes in custom designing storage systems for our customer’s application needs and budget with regard to product flow and material handling equipment. Our designs are targeted to maximize storage and increase your warehouse organization and business efficiency. The ware house design includes


"*" indicates required fields

Drop files here or
Max. file size: 50 MB.
    This field is for validation purposes and should be left unchanged.

    Our CAD department prepares a layout and provides preliminary floor plans using information provided by the salesperson or customer. Consult with customer and sales to determine functional and spatial requirements of warehouse, in order to maximize use of warehouse space. Apply knowledge of design, construction procedures, zoning and building codes, and building characteristics. Review customer profile and permit information to determine critical details of the project. Prepare scaled AutoCAD drawings and documents of project and integrate engineering elements into unified design. Contact the customers other contractors to provide plans for quoting proposes and review the projects scope with emphases on the expected time of completion.

    We create final plan drawings in accordance with local and uniform construction code requirements for township permit approval. Send the floor plans and detailed descriptions of the warehouse racking or other structures to an independent Professional Engineer for seismic certification along with sealed floor plans for egress and other requirements, according to building codes.

    We generate and submit all required documents for township, property owners and any other governing parties. Review plans with township officials for approval. Review material requirements and any expectable alternative materials with shop manager. Resolve any problems that occurred during project, such as field adjustments, use of alternate materials, permit issues.

    We coordinate with customer, sales, shop manager, contractors and township officials during and after installation. Review schedule to determine priority of assignments. Record and report the progress of projects as events merit. Schedule and coordinate inspections with township inspectors, customers, installers and contractors. Report results of final inspection for any corrections required or final payment.


    "I could not have been more pleased with the work these guys did. I received several quotes and theirs was the most professional by a long shot. The guys who did the installation were beyond amazing. They not only did a great job, but went out of their way to make sure everything was setup the way we wanted and cleaned up after they were done leaving the jobsite better than when they arrived. "
    - Tim P.
